Selection by Model Type :: Dipoles
Tuned Dipole Antennas
These half wavelength resonant dipole antennas are the foundation of every compliance testing lab. Initial designed by Willmar K. Roberts, these precision made half wavelength dipole antennas are the ideal solution for site attenuation measurments. Each antenna is manufactured with a balun loss of less than 0.5 dB and a VSWR of less than 1.5:1 The half wavelength resonant dipole antenna is the simplest antenna from a theoretical point of view, and are commonly used as a gain reference.
|
Model |
Frequency Range |
Description |
|
25 MHz - 1000 MHz |
FCC Balun Design, Single Set | |
|
25 MHz - 1000 MHz |
FCC Balun Design, Double Set | |
|
25 MHz - 70 MHz |
Dipole Antenna | |
|
65 MHz - 180 MHz |
Dipole Antenna | |
|
170 MHz - 340 MHz |
Dipole Antenna | |
|
325 MHz - 1000 MHz |
Dipole Antenna | |
|
also avaliable in 75 ohm | ||
VHF / UHF Dipole Antennas
|
Model |
Frequency Range |
Description |
|
50 MHz - 220 MHz, |
TV Dipole Set | |
|
50 MHz - 220 MHz |
Dipole Antenna | |
|
325 MHz - 1000 MHz |
Dipole Antenna | |
|
also avaliable in 75 ohm | ||
|
160 MHz - 500 MHz |
Broadband Dipole | |
|
160 MHz - 500 MHz |
Broadband Dipole, 300 Watts | |
Sleeve Dipole Antennas
Our new end-feed sleeve dipole antennas produce a truely omni-directional pattern with a typical gain of 2 dBi. As required by some automotive and wireless testing standards, the sleeve dipole antenna has an excellent VSWR and can be made to your specified frequency. These sleeve dipole antennas are also used as a reference for antenna gain measurements, wireless testing and chamber reflectivity evaluation.
|
Model |
Center Frequency |
Frequency Range |
|
900 MHz |
880 - 920 MHz | |
|
915 MHz |
890 - 940 MHz | |
|
1270 MHz |
1230 - 1320 MHz | |
|
1440 MHz |
1390 - 1500 MHz | |
|
1575 MHz |
1525 - 1725 MHz | |
|
1750 MHz |
1700 - 1800 MHz | |
|
1950 MHz |
1880 - 2010 MHz | |
|
2450 MHz |
2380 - 2570 MHz |
